Fuse panel locations and fuse box diagrams for: Mercedes-Benz B-Class (W245) 2005, 2006, 2007, 2008, 2009, 2010, 2011.

Source: https://fubox.net/mercedes-benz/b-class-2005-2011/

Fuse Box Diagrams and Fuse Panel Location for models:

2005 Mercedes-Benz B-Class
2006 Mercedes-Benz B-Class
2007 Mercedes-Benz B-Class
2008 Mercedes-Benz B-Class
2009 Mercedes-Benz B-Class
2010 Mercedes-Benz B-Class
2011 Mercedes-Benz B-Class

Mercedes-Benz B-Class (W245) Fuse Box Locations (2005–2012):

1. Passenger Compartment Fuse Box
Location: Under the floor near the passenger seat (or driver’s seat in RHD models). Remove the floor panel and cover.

2. Relay Panel (K100)
Location: Under the dashboard, often behind or near the main passenger compartment fuse box.
